Chapter 4

Device Management

RUGGEDCOM ROX II

CLI User Guide

62 Viewing the Parts List

Parameter Description

pm-slot Synopsis:  { pm1, pm2 }

The name of the power module slot as labeled on the chassis.

mov-protection Synopsis:  { na, working, damaged }

The state of the MOV protection circuit.

pm-temperature Synopsis:  A 32-bit signed integer between -55 and 125

The temperature (Celsius) inside the power module.

pm-current Synopsis:  A 32-bit signed integer between 0 and 15000

The current (mA) sourced by the power module.

pm-voltage Synopsis:  A 32-bit signed integer between 0 and 15000

The voltage (mV) sourced by the power module.

Section4.3

Viewing the Parts List

To view a list of parts installed in the device, type:

show running-config chassis part-list

If jobs have been configured, a table or list similar to the following example appears:

ruggedcom# show running-config chassis part-list | tab

MODEL ORDERFIELD PARTNUMBER PARTNAME

--------------------------------------------------------------------------------

RX5000 16TX01 12-86-0010-001 16x 10/100TX RJ45

RX5000 4CG01 12-86-0015-001 4x 10/100/1000TX RJ45

12-86-0203-001

RX5000 4CG02 12-86-0015-001 4x 10/100/1000TX microD

12-86-0204-001

RX5000 4FG01 12-86-0015-001 4x 1000SX Multimode 850nm LC 500m

12-86-0202-043

RX5000 4FG02 12-86-0015-001 4x 1000SX Singlemode 1310nm SC 10km

12-86-0202-021

RX5000 4FG03 12-86-0015-001 4x 1000LX Singlemode 1310nm LC 10km

12-86-0202-041

RX5000 4FG04 12-86-0015-001 4x 1000LX Singlemode 1310nm SC 25km

12-86-0202-022
