Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 12
Tunneling and VPNs
Viewing a List of GOOSE Tunnels 389
Parameter Description
mac Synopsis:  A string 17 characters long
The Multicast Destination MAC Address of the Goose message.
This parameter is mandatory.
rx-frames Synopsis:  A 32-bit unsigned integer
The number of frames received through the tunnel.
This parameter is mandatory.
tx-frames Synopsis:  A 32-bit unsigned integer
The number of frames transmitted through the tunnel.
This parameter is mandatory.
rx-chars Synopsis:  A 32-bit unsigned integer
The number of bytes received through the tunnel.
This parameter is mandatory.
tx-chars Synopsis:  A 32-bit unsigned integer
The number of bytes transmitted through the tunnel.
This parameter is mandatory.
errors Synopsis:  A 32-bit unsigned integer
The number of errors through the tunnel.
This parameter is mandatory.
Section12.5.2
Viewing a List of GOOSE Tunnels
To view a list of GOOSE tunnels, type:
show running-config tunnel l2tunneld goose
If tunnels have been configured, a table or list similar to the following example appears:
ruggedcom# show running-config tunnel l2tunneld goose tunnel | tab
IP
NAME INTERFACE MULTICAST MAC ADDRESS
-----------------------------------------------
1 switch.0001 01:0c:cd:01:01:01
!
If no GOOSE tunnels have been configured, add tunnels as needed. For more information, refer to Section12.5.3,
“Adding a GOOSE Tunnel”.
Section12.5.3
Adding a GOOSE Tunnel
To configure a GOOSE tunnel, do the following:
1. Make sure the CLI is in Configuration mode.
2. Add the tunnel by typing:
