Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 6
Security
Configuring the Source Zone 207
Parameter Description
• dnat: Forwards the request to another system and (optionally) another port.
• dnat-: Only generates the DNAT IPtables rule and not the companion ACCEPT rule.
• drop: The connection request is ignored. No notification is sent.
• redirect: Redirects the request to a local TCP port number on the local firewall.
• reject: Rejects the connection with an RST (TCP) or ICMP destination-unreachable.
source-zone-hosts { source-zone-hosts } Synopsis:  A string
(Optional) Add comma-separated host IPs to a predefined source-zone.
destination-zone-hosts { destination-zone-
hosts }
Synopsis:  A string
(Optional) Add comma-separated host IPs to the destination-zone - may include :port for
DNAT or REDIRECT.
log-level { log-level } Synopsis:  { none, debug, info, notice, warning, error, critical, alert, emergency }
Default:  none
(Optional) Determines whether or not logging will take place and at which logging level.
protocol { protocol } Synopsis:  { tcp, udp, icmp, all } or a string
Default:  all
The protocol to match for this rule - must be 'udp' for rules using copy-dnat actions.
source-ports { source-ports } Synopsis:  A string
Default:  none
(Optional) The TCP/UDP port(s) the connection originated from. Default: all ports. Add a
single port or a list of comma-separated ports
destination-ports { destination-ports } Synopsis:  A string
Default:  none
(Optional) The TCP/UDP port(s) the connection is destined for. Default: all ports. Add a
single port or a list of comma-separated ports
original-destination { original-destination } Synopsis:  { None } or a string
Default:  none
(Optional) The destination IP address in the connection request as it was received by the
firewall - (mandatory) for rules using copy-dnat actions.
description { description } Synopsis:  A string
(Optional) The description string for this rule.
4. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section6.9.15.3
Configuring the Source Zone
To configure the source zone for a firewall rule, do the following:
1. Make sure the CLI is in Configuration mode.
2. Navigate to security» firewall» fwconfig» {firewall}» fwrule{rule}» source-zone, where {firewall} is the
name of the firewall and {rule} is the name of the rule.
3. Configure the following parameter(s) as required:
Parameter Description
predefined-zone { predefined-zone } Synopsis:  A string
A predefined zone
