Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 13
Unicast and Multicast Routing
Viewing a List of Area Tags 447
Section13.6.5.1
Viewing a List of Area Tags
To view a list of area tags configured for dynamic IS-IS routes, type:
show running-config routing isis area
If area tags have been configured, a table or list similar to the following example appears:
ruggedcom# show running-config routing isis area
routing isis
area Area_1
is-type level-1-2
metric-style narrow
area-authorization md5
area-password admin
area-authentication validate
domain-authorization md5
domain-password admin
domain-authentication validate
net 49.0001.1921.6800.1001.00
!
redistribute bgp
is-type level-1-2
metric-type internal
metric 10
!
lsp-gen-interval is-type level-1-only
interval 60
!
lsp-refresh-interval is-type level-1-2
interval 20
!
max-lsp-lifetime is-type level-2-only
interval 10
!
spf-interval is-type level-1-2
interval 5
!
!
!
If no area tags have been configured, add area tags as needed. For more information, refer to Section13.6.5.2,
“Adding an Area Tag”.
Section13.6.5.2
Adding an Area Tag
To add an area tag for dynamic IS-IS routes, do the following:
1. Make sure the CLI is in Configuration mode.
2. Add the area by typing:
routing isis area name
Where:
• name is the unique name for a routing process that belongs to a specific router.
3. Configure the following parameter(s) as required:
