Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 12
Tunneling and VPNs
Viewing a List of Generic Tunnels 393
Parameter Description
The number of frames received through the tunnel.
This parameter is mandatory.
tx-frames Synopsis:  A 32-bit unsigned integer
The number of frames transmitted through the tunnel.
This parameter is mandatory.
rx-chars Synopsis:  A 32-bit unsigned integer
The number of bytes received through the tunnel.
This parameter is mandatory.
tx-chars Synopsis:  A 32-bit unsigned integer
The number of bytes transmitted through the tunnel.
This parameter is mandatory.
errors Synopsis:  A 32-bit unsigned integer
The number of errors received through the tunnel.
This parameter is mandatory.
Section12.6.2
Viewing a List of Generic Tunnels
To view a list of generic tunnels, type:
show running-config tunnel l2tunneld generic tunnel
If tunnels have been configured, a table or list similar to the following example appears:
ruggedcom# show running-config tunnel l2tunneld generic tunnel | tab
REPLACE EGRESS IP
NAME INGRESS IF MAC TYPE IF ADDRESS
---------------------------------------------------
1 switch.0001 -
iso
!
If no generic tunnels have been configured, add tunnels as needed. For more information, refer to Section12.6.3,
“Adding a Generic Tunnel”.
Section12.6.3
Adding a Generic Tunnel
To configure a generic tunnel, do the following:
1. Make sure the CLI is in Configuration mode.
2. Add the tunnel by typing:
tunnel l2tunneld generic tunnel name
Where:
• name is the name of the generic tunnel
