Siemens RUGGEDCOM ROX II User Manual

Chapter 16
Traffic Control and Classification
RUGGEDCOM ROX II
CLI User Guide
698 Adding a Traffic Control Class
Section16.2.4.2
Adding a Traffic Control Class
To add a new traffic control class, do the following:
1. Make sure the CLI is in Configuration mode.
2. Add the static MAC address by typing:
qos traffic-control advanced-configuration tcclasses name
Where:
• name is the name of the traffic control class entry
3. Configure the following parameter(s) as required:
Parameter Description
iptype { iptype } Synopsis:  { ipv4, ipv6, ipv4ipv6 }
Default:  ipv4
Internet protocol type - use both when no addresses are used, otherwise define IPv4 and
IPv6 rules for each type of addresses used.
interface { interface } Synopsis:  A string
The interface to which this class applies. Each interface must be listed only once.
Lowercase alphanumerical as well as '.' and '-' characters are allowed.
This parameter is mandatory.
mark { mark } Synopsis:  A 16-bit unsigned integer between 1 and 255
A mark that identifies traffic belonging to this class. This is a unique integer between
1-255. Each class must have its own unique mark.
This parameter is mandatory.
min-bandwidth { min-bandwidth } Synopsis:  A string
The minimum bandwidth this class should have when the traffic load rises. This can
be either a numeric value or a calculated expression based on the bandwidth of the
interface. A fixed numerical value must only be a number - its unit is specified in Minbw-
unit.
A calculated expression is based on a fraction of the 'full' bandwidth, such as:
• 'full/3' for a third of the bandwidth and
• 'full*9/10' for nine tenths of the bandwidth.
In such a case, do not specify any minbw-unit.
This parameter is mandatory.
minbw-unit { minbw-unit } Synopsis:  { none, kilobits, megabits }
Default:  none
(per second) Only if the minimum bandwidth is a <b>single numerical value</b>
max-bandwidth { max-bandwidth } Synopsis:  A string
The maximum bandwidth this class is allowed to use when the link is idle. This can
be either a numeric value or a calculated expression based on the bandwidth of the
interface. A fixed numerical value must only be a number - its unit is specified in Maxbw-
unit.
A calculated expression is based on a fraction of the 'full' bandwidth, such as:
• 'full/3' for a third of the bandwidth and
• 'full*9/10' for nine tenths of the bandwidth.
In such a case, do not specify any maxbw-unit.
This parameter is mandatory.
