Chapter 13

Unicast and Multicast Routing

RUGGEDCOM ROX II

CLI User Guide

550 Deleting a Static Cross-Connect

3. Configure the following parameter(s) as required:

Parameter Description

out-interface { out-interface } Synopsis:  A string

The outgoing interface.

This parameter is mandatory.

next-hop { next-hop } Synopsis:  A string 7 to 15 characters long or a string 6 to 40 characters long

The destination next-hop router (IPv4 or IPv6 format).

This parameter is mandatory.

out-label { out-label } Synopsis:  { explicit-null, implicit-null } or a 32-bit unsigned integer between 16 and

1048575

The outgoing label: 'explicit-null', 'implicit-null' or integer 16 -> 1048575.

This parameter is mandatory.

4. Type commit and press Enter to save the changes, or type revert and press Enter to abort.

Section13.10.6.4

Deleting a Static Cross-Connect

To delete a static cross-connect, do the following:

1. Make sure the CLI is in Configuration mode.

2. Delete a static cross-connect by typing:

no mpls static-mpls crossconnect in-label in-label

Where:

• in-label is the incoming label

3. Type commit and press Enter to save the changes, or type revert and press Enter to abort.

Section13.10.7

Managing LDP

LDP (Label Distribution Protocol), defined by RFC 5036 [http://tools.ietf.org/html/rfc5036], is a protocol that

enables an MPLS capable router to exchange MPLS label information. The labels are distributed in both directions

so that an LSP (Label Switched Path) can be established and managed within an MPLS network dynamically, as

opposed to configuring static routes. LDP takes advantage of already established routing information (using OSPF

or IS-IS) to distribute label information amongst the MPLS enabled routers).

LDP works by enabling Label Switch Routers (LSRs) to discover and bind labels to their neighbors within the

MPLS network. The LSRs then identify their peers and exchange their label information with one another. Label

information is stored in Label Information Base (LIB) and Label Forwarding Information Base (LFIB) tables.

CONTENTS

• Section13.10.7.1, “Viewing the Status of LDP Binding”

• Section13.10.7.2, “Viewing the Status of the LDP Discovery Interfaces”

• Section13.10.7.3, “Viewing the Status of the LDP Neighbor Local Node Information”
