RUGGEDCOM ROX II
CLI User Guide
Chapter 8
Layer 2
Managing Egress Ports for Multicast Groups 299
Section8.4.5
Managing Egress Ports for Multicast Groups
This section describes how to configure and manage egress ports for a multicast group.
CONTENTS
• Section8.4.5.1, “Viewing a List of Egress Ports”
• Section8.4.5.2, “Adding an Egress Port”
• Section8.4.5.3, “Deleting an Egress Port”
Section8.4.5.1
Viewing a List of Egress Ports
To view a list of egress ports for a static multicast group defined in the Static Multicast Group Summary table,
type:
show switch mcast-filtering static-mcast-table id address egress-ports
Where:
• id is the ID for the VLAN upon which the static multicast group operates
• address is the MAC address for the device in the form of 01:xx:xx:xx:xx:xx
If egress ports have been established, a table or list similar to the following example appears:
ruggedcom# show running-config switch mcast-filtering static-mcast-table 10 01:00:00:01:01:01 egress-
ports
switch mcast-filtering
static-mcast-table 10 01:00:00:01:01:01
egress-ports lm2 1
!
!
!
If no egress ports have been configured, add egress ports as needed. For more information, refer to
Section8.4.5.2, “Adding an Egress Port”.
Section8.4.5.2
Adding an Egress Port
To add an egress port to a static multicast group defined in the Static Multicast Group Summary table, do the
following:
1. Make sure the CLI is in Configuration mode.
2. Add the egress port by typing:
switch mcast-filtering static-mcast-table id address egress-ports slot port
Where:
• id is the ID for the VLAN upon which the static multicast group operates
• address is the MAC address for the device in the form of 01:xx:xx:xx:xx:xx
