RUGGEDCOM ROX II
CLI User Guide
Chapter 13
Unicast and Multicast Routing
Managing Redistribution for IPv4 Address Families 571
1. Make sure the CLI is in Configuration mode.
2. Delete the IPv4 address family by typing:
no routing bgp address-family ipv4 vrf vrf
Where:
• vrf is the name of the associated VRF definition
3. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section13.11.11
Managing Redistribution for IPv4 Address Families
Redistribution in general is the advertisement of routes by one protocol that have been learned via another
dynamic routing protocol, a static route, or a directly connected router. It is deployed to promote interoperability
between networks running different routing protocols. In the case of VRF, the OSPF dynamic routing protocol is
supported.
For each VRF instance, one or more redistributions can be defined. A redistribution defines the source of the
routing information, a metric and (optional) a pre-defined routing map.
The metric is used for route decision making within the Autonomous System (AS). Care must be taken to define a
metric that is understood by the OSPF routing protocol.
CONTENTS
• Section13.11.11.1, “Viewing a List of Redistributions”
• Section13.11.11.2, “Adding a Redistribution”
• Section13.11.11.3, “Deleting a Redistribution”
Section13.11.11.1
Viewing a List of Redistributions
To view a list of redistributions for an IPv4 address family, type:
show running-config routing bgp address-family ipv4 vrf vrf redistribute
Where:
• vrf is the chosen VRF instance
If redistributions have been configured, a table or list similar to the following example appears:
ruggedcom# show running-config routing bgp address-family ipv4 vrf VRF1 redistribute | tab
ROUTE
SOURCE METRIC MAP
--------------------------
connected - -
ospf - -
static - -
!
!
!
