Siemens RUGGEDCOM ROX II User Manual

Chapter 8
Layer 2
RUGGEDCOM ROX II
CLI User Guide
272 Viewing Switched Ethernet Port Statistics
Parameter Description
• ADVERTISE ONLY : the port will declare all VLANs existing in the switch (configured or
learned) but will not learn any VLANs.
• ADVERTISE and LEARN : the port will declare all VLANs existing in the switch
(configured or learned) and can dynamically learn VLANs.
NOTE
Once a VLAN ID has been assigned to a switched Ethernet port, a VLAN is created and can be
configured in switch» vlans» all-vlans.
9. If the port is in switchport mode, configure the VLAN for the port. For more information, refer to
Section8.5.4.2, “Configuring VLANs for Switched Ethernet Ports”.
10. Configure the port security settings. For more information, refer to Section6.6.2, “Configuring Port Security”.
11. Configure the spanning tree settings. For more information, refer to Section14.3.5, “Configuring STP for
Switched Ethernet Ports and Ethernet Trunk Interfaces”.
12. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section8.1.3
Viewing Switched Ethernet Port Statistics
To view statistics collected for a specific switched Ethernet port, type:
show interfaces switch slot port port-stats
Where:
• slot is the name of the module location
• port is the port number (or a list of ports, if aggregated in a port trunk) for the module
A table or list similar to the following example appears:
ruggedcom# show interfaces switch lm1 1 port-stats
port-stats
in octets 6820
out octets 3086
in pkts 33
out pkts 18
error pkts 0
This table or list provides the following information:
Parameter Description
in-octets Synopsis:  A 32-bit unsigned integer
The number of octets in received good packets. (Unicast+Multicast+Broadcast) and dropped
packets.
This parameter is mandatory.
out-octets Synopsis:  A 32-bit unsigned integer
The number of octets in transmitted good packets.
This parameter is mandatory.
in-pkts Synopsis:  A 32-bit unsigned integer
The number of received good packets (Unicast+Multicast+Broadcast) and dropped packets.
