Siemens RUGGEDCOM ROX II User Manual

Chapter 13
Unicast and Multicast Routing
RUGGEDCOM ROX II
CLI User Guide
546 Managing Static Label Binding
Disable
no mpls interface-mpls interface enable
Where:
• interface is the name of the interface
3. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section13.10.5
Managing Static Label Binding
This section describes how to bind (or reserve) labels for IPv4 or network prefixes.
CONTENTS
• Section13.10.5.1, “Viewing the Status of Static Label Binding”
• Section13.10.5.2, “Viewing a List of Static Labels”
• Section13.10.5.3, “Adding a Static Label”
• Section13.10.5.4, “Deleting a Static Label”
Section13.10.5.1
Viewing the Status of Static Label Binding
To view the status of all configured static label binding, type:
show mpls status static-binding
If static label binding has been configured, a table similar to the following example appears:
ruggedcom# show mpls status static-binding
IN OUT
IP ADDRESS LABEL LABEL NEXTHOP
----------------------------------------------
192.168.20.0/24 90 101 192.168.10.2
192.168.200.0/24 95 100 192.168.10.2
This table provides the following information:
Parameter Description
ip-address Synopsis:  A string
The destination address prefix.
in-label Synopsis:  A string
The incoming (local) label.
out-label Synopsis:  A string
The outgoing (remote) label.
nexthop Synopsis:  A string
The destination next hop router.
