Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 4
Device Management
Viewing a List of Line Module Configurations 95
After the device is rebooted, the new line module is automatically detected and operational.
6. If the line module is different from the previous module installed in the same slot, add a configuration for the
new line module. For more information, refer to Section4.16.4, “Configuring a Line Module”.
Section4.16.3
Viewing a List of Line Module Configurations
To view a list of line module configurations, type:
show running-config chassis line-modules
If line modules have been configured, a table or list similar to the following example appears:
ruggedcom# show running-config chassis line-modules | tab
chassis
line-modules
line-module
ADMIN ADMIN
SLOT MODULE TYPE ENABLED BYPASS
----------------------------------------------------------------------
sm SM 8 Gigabit Layer 2 w/ 2x 10/100/1000TX RJ45 X -
lm1 none - -
lm2 4x 1000LX SFP X -
lm3 16x 10/100TX RJ45 X -
lm4 8x 100FX SFP X -
lm5 none - -
lm6 none - -
!
!
If no line modules have been configured, install line module as needed. For more information, refer to
Section4.16.2, “Installing a New Line Module”.
Section4.16.4
Configuring a Line Module
To configure a line module, do the following:
1. Make sure the CLI is in Configuration mode.
2. Navigate to chassis» line-modules» line-module» {module}, where {module} is the line module.
3. Configure the following parameter(s) as required:
Parameter Description
{ slot } Synopsis:  { sm, lm1, lm2, lm3, lm4, lm5, lm6, swport, eth, serport, celport, wlanport }
The slot name, as marked on the silkscreen across the top of the chassis.
detected-module Synopsis:  A string 1 to 60 characters long
The installed module's type specifier.
This parameter is mandatory.
module-type { module-type } Synopsis:  A string
Sets the module type to be used in this slot.
