Chapter 14
Network Redundancy
RUGGEDCOM ROX II
CLI User Guide
660 Viewing the Proxy Nodes Table
NOTE
Setting life-check-interval to 0 will disable the generation of supervision frames.
interface switch slot port rna life-check-interval interval
Where:
• slot is the slot where the chosen PRP module resides.
• port is the chosen port on the PRP module.
• interval is the interval in seconds (s). The default is 2.
3. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section14.4.3
Viewing the Proxy Nodes Table
The proxy nodes table details information about each VDAN for which the device acts as a proxy to the
redundancy network.
To view the nodes table, type:
show switch rna proxy-node-table
A table similar to the following appears:
ruggedcom# show switch rna proxy-node-table | tab
LRE
INTERFACE
STATS LRE PROXY LRE PROXY NODE
INDEX NODE INDEX MAC ADDRESS
------------------------------------------
129 1892881004 00:0a:dc:ee:b9:80
129 2063258065 00:0a:dc:ee:b9:81
This table displays the following information about each node:
Parameter Description
lreInterfaceStatsIndex Synopsis: A 32-bit unsigned integer
A unique value for each LRE.
lreProxyNodeIndex Synopsis: A 32-bit unsigned integer
A unique value for each node in the LRE's proxy node table.
lreProxyNodeMacAddress Synopsis: A string
Each entry contains information about a particular node for which the LRE acts as a proxy for
the HSR/PRP network.
Section14.4.4
Viewing the Nodes Table
The nodes table is a list of all learned MAC addresses for DAN and SAN devices on the redundancy network.
To view the nodes table, type:
