Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 14
Network Redundancy
Viewing Statistics Collected for RNA Ports 661
show interfaces switch rna nodesTable
A table similar to the following appears:
ruggedcom# show interfaces switch rna nodesTable
LRE
INTERFACE LRE TIME LRE TIME LRE REM
STATS LRE NODES LRE NODES MAC LAST LAST NODE
INDEX INDEX ADDRESS SEEN A SEEN B TYPE
-----------------------------------------------------------------------
129 3003009056 00:0a:dc:af:e4:e0 42394000 42183000 redboxp
This table displays the following information about each node:
Parameter Description
lreInterfaceStatsIndex Synopsis:  A 32-bit unsigned integer
A unique value for each LRE.
lreNodesIndex Synopsis:  A 32-bit unsigned integer
Unique value for each node in the LRE's node table.
lreNodesMacAddress Synopsis:  A string
Each MAC address corresponds to a single Dual Attached Node
lreTimeLastSeenA Synopsis:  A string
Time in TimeTicks (1/100s) since the last frame from this remote LRE was received over LAN
A. Initialized with a value of 0 upon node registration in the node table.
lreTimeLastSeenB Synopsis:  A string
Time in TimeTicks (1/100s) since the last frame from this remote LRE was received over LAN
B. Initialized with a value of 0 upon node registration in the node table.
lreRemNodeType Synopsis: 
DAN type, as indicated in the received supervision frame
Section14.4.5
Viewing Statistics Collected for RNA Ports
The device collects statistics on traffic traversing the RNA ports.
NOTE
Statistics displayed are not updated automatically.
Redundant Network Access Port Statistics
Type the following command to view the the number of nodes the RedBox is aware of on the redundancy and
non-redundancy sides of the network. It also displays the MAC address being broadcast in supervision frames.
show interfaces switch slot port rna
Where:
• slot is the slot where the chosen PRP module resides
• port is the chosen port on the PRP module
