Siemens RUGGEDCOM ROX II User Manual

Chapter 8
Layer 2
RUGGEDCOM ROX II
CLI User Guide
310 Managing VLANs for Switched Ethernet Ports
Section8.5.4
Managing VLANs for Switched Ethernet Ports
This section describes how to configure and manage VLANs assigned to switched Ethernet ports.
CONTENTS
• Section8.5.4.1, “Viewing VLAN Assignments for Switched Ethernet Ports”
• Section8.5.4.2, “Configuring VLANs for Switched Ethernet Ports”
Section8.5.4.1
Viewing VLAN Assignments for Switched Ethernet Ports
To determine which VLANs are assigned to each switched Ethernet port, type:
show switch vlans vlan-summary
A table similar to the following example appears:
ruggedcom# show switch vlans vlan-summary
IGMP UNTAGD UNTAGD TAGGED TAGGED
VID SNOOPING MSTI SLOT PORTS SLOT PORTS QOS INGRESS MARK
-------------------------------------------------------------------------
1 false 0
sm none
lm1 1,2
lm2 none
lm3 none
lm4 none
lm5 none
lm6 none
sm none
lm1 none
lm2 none
lm3 none
lm4 none
lm5 none
lm6 none
0 0
1 0
2 0
3 0
4 0
.
.
.
The VLANs listed are based on the PVIDs assigned to the switched Ethernet ports. For more information about
assigning PVIDs to switched Ethernet Ports, refer to Section8.1.2, “Configuring a Switched Ethernet Port”.
Section8.5.4.2
Configuring VLANs for Switched Ethernet Ports
When a VLAN ID is assigned to a switched Ethernet port, the VLAN appears in the All-VLANs Table where it can be
further configured.
To configure a VLAN for a switched Ethernet port, do the following:
