282 Adding an Ethernet Trunk Interface
Parameter Description
• ADVERTISE ONLY : the port will declare all MCAST addresses existing in the switch
(configured or learned) but will not learn any MCAST addresses.
• ADVERTISE and LEARN : the port will declare all MCAST Addresses existing in the switch
(configured or learned) and can dynamically learn MCAST addresses.
5. Configure the CoS settings by typing the following commands:
Parameter Description
default-priority { default-priority } Synopsis:  A 32-bit signed integer between 0 and 7
Default:  0
The priority of frames received on this port that are not prioritized based on the frame's
contents (e.g. priority field in the VLAN tag, DiffServ field in the IP header, prioritized
MAC address).
inspect-tos Enables or disables parsing of the Type-Of-Service (TOS) field in the IP header of the
received frames to determine what Class of Service they should be assigned. When TOS
parsing is enabled the switch will use the Differentiated Services bits in the TOS field.
6. Configure the VLAN settings by typing the following commands:
Parameter Description
pvid { pvid } Synopsis:  A 32-bit signed integer between 1 and 4094
The Port VLAN Identifier specifies the VLAN ID associated with untagged (and 802.1p
priority tagged) frames received on this port. Frames tagged with a non-zero VLAN ID
will always be associated with the VLAN ID retrieved from the frame tag.
type { type } Synopsis:  { edge, trunk, pvlanedge }
Default:  edge
How the port determines its membership in VLANs. There are the following port types:
• EDGE : the port is only a member of one VLAN (its native VLAN specified by the'PVID'
parameter).
• PVLAN Edge : the port does not forward traffic to other PVLAN edge ports within the
same VLAN.
• TRUNK : the port is automatically a member of all configured VLANs. Frames
transmitted out of the port on all VLANs except the port's native VLAN will be always
tagged. It can also be configured to use GVRP for automatic VLANconfiguration.
format { format } Synopsis:  { untagged, tagged }
Default:  untagged
Whether frames transmitted out of the port on its native VLAN(specified by the 'PVID'
parameter) will be tagged or untagged.
gvrp-mode { gvrp-mode } Synopsis:  { advertise_only, learn_advertise }
GVRP (Generic VLAN Registration Protocol) operation on the port. There are several GVRP
operation modes:
• DISABLED : the port is not capable of any GVRP processing.
• ADVERTISE ONLY : the port will declare all VLANs existing in the switch (configured or
learned) but will not learn any VLANs.
• ADVERTISE and LEARN : the port will declare all VLANs existing in the switch
(configured or learned) and can dynamically learn VLANs.
7. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
