Siemens RUGGEDCOM ROX II

Chapter 12
Tunneling and VPNs
RUGGEDCOM ROX II
CLI User Guide
430 Understanding DMVPN
2
2
2
1
3
4
Figure20:Hub-and-Spoke Topology – Single Hub
1.Hub (Static IP Address) 2.Spoke (Static IP Address) 3.Hub-to-Spoke GRE/IPsec Tunnel
Spokes can also be connected to a secondary hub when redundancy is required.
2
2
2
1
3
4
1
Figure21:Hub-and-Spoke Topology – Dual Hub
1.Hub (Static IP Address) 2.Spoke (Static IP Address) 3.Hub-to-Spoke GRE/IPsec Tunnel
