RUGGEDCOM ROX II

CLI User Guide

Chapter 13

Unicast and Multicast Routing

Understanding Route Reflectors 505

RR1 RR2

RR3 RR4

Figure26:Multiple Clusters Fully-Meshed

Route reflectors can also be partially-meshed by combining them in a cluster of their own.

RR1

RR3 RR4RR2

Figure27:Multiple Clusters Partially-Meshed

Redundant Route Reflectors

To avoid a single point of failure in the BGP network, each cluster should be served by more than one route

reflector to provide redundancy in case of failure. In this arrangement, each route reflectors are configured to

have the same BGP neighbors as clients.
