Siemens RUGGEDCOM ROX II User Manual

Chapter 13
Unicast and Multicast Routing
RUGGEDCOM ROX II
CLI User Guide
510 Example: Linking Clusters
Final Configuration Example
RR1 (172.30.110.10)
routing bgp
enabled
as-id 100
route-reflector cluster-id 0.1.2.3
!
neighbor 172.30.110.20 { RR2 }
remote-as 100
no route-reflector-client enabled
!
neighbor 172.30.110.30 { RR3 }
remote-as 100
no route-reflector-client enabled
!
neighbor 172.30.140.10 { Client }
remote-as 100
route-reflector-client enabled
!
neighbor 172.30.140.20 { Client }
remote-as 100
route-reflector-client enabled
!
neighbor 172.30.140.30 { Client }
remote-as 100
route-reflector-client enabled
!
!
RR2 (172.30.110.20)
routing bgp
enabled
as-id 100
route-reflector cluster-id 10.11.12.13
!
neighbor 172.30.110.10 { RR1 }
remote-as 100
no route-reflector-client enabled
!
neighbor 172.30.110.30 { RR3 }
remote-as 100
no route-reflector-client enabled
!
neighbor 172.30.150.10 { Client }
remote-as 100
route-reflector-client enabled
!
neighbor 172.30.150.30 { Client }
remote-as 100
route-reflector-client enabled
!
neighbor 172.30.150.20 { Client }
remote-as 100
route-reflector-client enabled
!
!
RR3 (172.30.110.30)
routing bgp
enabled
as-id 100
route-reflector cluster-id 20.21.22.23
