2-18
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 2 Connect the PC and Log into the GUI
DLP-G41 Set Up a Windows PC for Craft Connection to an ONS 15454 Using Automatic Host Detection
o. Proceed to Step 7.
Step 5 If you have Windows 2000 installed on your PC, complete the following steps to change its TCP/IP
configuration:
a. From the Windows Start menu, choose Settings > Network and Dial-up Connections >
Local Area Connection.
b. In the Local Area Connection Status dialog box, click Properties.
c. On the General tab, choose Internet Protocol (TCP/IP), then click Properties.
d. Click Use the following IP address.
e. In the IP Address field, enter any legitimate IP address other than the node IP address as indicated
on the LCD of the ONS 15454. The default IP address is 192.1.0.2.
Note You can suppress the LCD IP address display using CTC. For more information, see the
“DLP-G162 Change IP Settings” task on page 10-19.
f. In the Subnet Mask field, type the same subnet mask as the ONS 15454. The default is
255.255.255.0 (24 bit).
g. Type the IP address entered in Step e in the Gateway Address field.
h. Click OK.
i. In the Local Area Connection Properties dialog box, click OK.
j. In the Local Area Connection Status dialog box, click Close.
k. Proceed to Step 7.
Step 6 If you have Windows XP installed on your PC, complete the following steps to change its TCP/IP
configuration:
a. From the Windows Start menu, choose Control Panel > Network Connections.
Note If the Network Connections menu is not available, click Switch to Classic View.
b. From the Network Connections dialog box, click the Local Area Connection icon to select it.
Right-click and select Properties.
c. From the Local Area Connection Properties dialog box, click on Internet Protocol (TCP/IP) to
select it, then click Properties.
d. In the IP Address field, enter any legitimate IP address other than the node IP address as indicated
on the LCD of the ONS 15454. The default IP address is 192.1.0.2.
e. Select the Use the Following IP Address: radio button.
Note You can suppress the LCD IP address display using CTC. For more information, see the
“DLP-G162 Change IP Settings” task on page 10-19.
f. In the Subnet Mask field, type the same subnet mask as the ONS 15454. The default is
255.255.255.0 (24 bit).
g. Type the IP address entered in Step d in the Gateway Address field.
h. Click OK.
