3-71
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 3 Turn Up a Node
DLP-G71 Install Fiber-Optic Cables for an ROADM Node
Step 2 Plug one end of the fiber into the desired RX port.
Step 3 Route the fiber cable on the card faceplate through the fiber clip on the faceplate, if provided. (Fiber clips
are factory-attached to the faceplates of 32WSS, 32DMX-O, OSCM, OPT-PRE, and OPT-BST cards.)
Step 4 Route the fiber cable through the cable-routing channel and cutout on the appropriate side of the shelf
assembly, as necessary (Figure 15-35 on page 15-37).
Step 5 As needed, route slack fiber-optic cable around the round cable retainers in the fiber-storage tray
(Figure 15-38 on page 15-40).
Caution When you close the fiber-storage tray, the cables must not be pinched, and the cable bend radius must
be equal to or greater than the minimum radius that is recommended in your site specifications. As you
route each cable through the fiber-storage tray, make sure that adequate cable slack remains.
Step 6 Route the fiber cable out either side of the fiber-storage tray as necessary.
Step 7 Plug the other end of the cable into the correct TX port.
Note Cards display an SF LED after the OSC terminations are created (see the “NTP-G38 Provision
OSC Terminations” procedure on page 3-84) if transmit and receive fibers are not connected
correctly. For example, an RX port is connected to another RX port or a TX port is connected to
another TX port.
Step 8 Repeat 2 through 7 until you have connected the node(s) according to the site plan.
Step 9 Return to your originating procedure (NTP).
5 West 32WSS COM RX to west OPT-PRE COM TX 12 East OPT-BST COM TX to east OPT-PRE COM RX
6 West 32DMX COM RX to west 32WSS DROP TX 13 East DCU RX to east OPT-PRE DC TX
1
7 West 32WSS EXP TX to east 32WSS EXP RX 14 East DCU TX to east OPT-PRE DC RX
1
1. If a DCU is not installed, a 4-dB attenuator loop, +/–1 dB must be installed between the OPT-PRE DC ports.
