Chapter 4 Perform Node Acceptance Tests
NTP-G43 Perform the ROADM Node Acceptance Test
Step 2 Complete the “DLP-G46 Log into CTC” task on page 2-25 at the ROADM node that you want to test.
If you are already logged in, continue with Step 3.
Table 4-2 32WSS Ports and Wavelengths Test Checklist
32WSS Provisioning
Subtab Port # Wavelength
Tested
PT
Tested
Add/Drop
West
Tested
Add/Drop
East
Optical Chn:
Optical Connector 1
RX 1, PT 33 1530.33
RX 2, PT 34 1531.12
RX 3, PT 35 1531.90
RX 4, PT 36 1532.68
RX 5, PT 37 1534.25
RX 6, PT 38 1535.04
RX 7, PT 39 1535.82
RX 8, PT 40 1536.61
Optical Chn:
Optical Connector 2
RX 9, PT 41 1538.19
RX 10, PT 42 1538.98
RX 11, PT 43 1539.77
RX 12, PT 44 1540.56
RX 13, PT 45 1542.14
RX 14, PT 46 1542.94
RX 15, PT 47 1543.73
RX 16, PT 48 1544.53
Optical Chn:
Optical Connector 3
RX 17, PT 49 1546.12
RX 18, PT 50 1546.92
RX 19, PT 51 1547.72
RX 20, PT 52 1548.51
RX 21, PT 53 1550.12
RX 22, PT 54 1550.92
RX 23, PT 55 1551.72
RX 24, PT 56 1552.52
Optical Chn:
Optical Connector 4
RX 25, PT 57 1554.13
RX 26, PT 58 1554.94
RX 27, PT 59 1555.75
RX 28, PT 60 1556.55
RX 29, PT 61 1558.17
RX 30, PT 62 1558.98
RX 31, PT 63 1559.79
RX 32, PT 64 1560.61
