Chapter 4 Perform Node Acceptance Tests
NTP-G43 Perform the ROADM Node Acceptance Test
Step 3 Display the ROADM node in node view.
Step 4 Click the Alarms tab.
a. Verify that the alarm filter is not on. See the “DLP-G128 Disable Alarm Filtering” task on page 8-28
as necessary.
b. Verify that no equipment (EQPT) alarms appear indicating equipment failure or other hardware
problems. If equipment failure alarms appear, investigate and resolve them before continuing. Refer
to the Cisco ONS 15454 Troubleshooting Guide or the Cisco ONS 15454 SDH Troubleshooting
Guide for procedures.
Note The OSC terminations created during node turn-up will generate two alarms for each side of the
shelf, one for LOS on the OPT-BST card, and the other an LOS alarm on the OSC-CSM or
OSCM card.
Step 5 In node view, click the Provisioning > WDM-ANS > Port Status tabs. Verify that all statuses under
Link Status are listed as Success - Changed, Success - Unchanged, or Not Applicable. If any are not,
complete the following steps:
a. Delete the two OSC channels using the “DLP-G186 Delete an OSC Termination” task on
page 10-41.
b. Complete the “NTP-G37 Run Automatic Node Setup” procedure on page 3-83.
c. Create the OSC channels using the “NTP-G38 Provision OSC Terminations” procedure on
page 3-84.
Step 6 Display the east 32WSS in card view.
Step 7 Click the Provisioning > Optical Chn Optical Connector [n] > Parameters tabs, where n = the optical
connector number that carries the wavelengths you will test. Refer to Table 4-2 on page 4-9, if needed.
Step 8 Click the Admin State table cell for the Add port carrying the tested wavelength, then choose OOS,MT
(for ANSI) or Locked,maintenance (ETSI) from the drop-down list. For example, if the tested
wavelength is 1530.33 (shown as 1530.3), you would click the Port 1 Admin State field and choose
OOS,MT or Locked,maintenance from the drop-down list.
Step 9 Change the Admin State of the PT port corresponding to the port in Step 8 to OOS,MT (ANSI) or
Locked,maintenance (ETSI). For example, if the tested wavelength is 1530.33 (shown as 1530.3), you
would click the Port 33 Admin State field and choose OOS,MT or Locked,maintenance from the
drop-down list. Refer to Table 4-2 on page 4-9, if needed.
Step 10 Click Apply, then click Ye s to confirm.
Step 11 Repeat Steps 7 through 10 for all wavelengths that you will test.
Step 12 Display the west 32WSS in card view.
Step 13 Repeat Steps 7 through 10 for the west 32WSS card.
Step 14 Display the east 32DMX or 32DMX-O in card view and complete the following steps:
For a 32DMX card:
a. Choose the Provisioning > Optical Line > Parameters tabs.
b. For Port 33, click the Admin State table cell and choose OOS,MT (ANSI) or Locked,maintenance
(ETSI) from the drop-down list.
c. Click Apply, then click Yes to confirm.
