Chapter 4 Perform Node Acceptance Tests
NTP-G47 Perform the Line Amplifier Node with OSCM and OSC-CSM Cards Acceptance Test
i. Wait 90 seconds, then in node view click the Alarms tab. Verify that the LOS alarm on the OSCM
card has cleared. If so, replace the OPT-BST card. If not, replace the OSCM card. See the “NTP-G30
Install the DWDM Cards” procedure on page 3-39.
Step 26 Connect the tunable laser transmitter or the TXP_MR_2.5G card DWDM TX port to the OSC-CSM
LINE RX port using a 10-dB bulk attenuator.
Step 27 If an OPT-PRE is installed on the same side of the shelf as the OSC-CSM, complete the “DLP-G80
Verify the OPT-PRE Amplifier Laser and Power” task on page 4-41. If not, continue with Step 27.
Step 28 Complete the “DLP-G79 Verify the OPT-BST Amplifier Laser and Power” task on page 4-40 for the
OPT-BST card.
Step 29 Display the OSC-CSM card in card view.
Step 30 Click the Provisioning > Optical Line > Parameters tabs. Verify that the power value on Port 3
(Out Com) is equal to the optical power from the tunable laser or TXP_MR_2.5G card (measured in
Step 10) +/– 1 dBm.
Step 31 If an OPT-PRE card is installed on the side opposite the OSC-CSM, complete the “DLP-G80 Verify the
OPT-PRE Amplifier Laser and Power” task on page 4-41. If not, continue with Step 32.
Step 32 Disconnect the TXP or tunable laser from the OSC-CSM card.
Step 33 Remove the loopback fiber on the OPT-BST amplifier card.
Step 34 Delete both OSC channels. See the “DLP-G186 Delete an OSC Termination” task on page 10-41.
Step 35 Complete the “NTP-G37 Run Automatic Node Setup” procedure on page 3-83 to restore the original
configuration.
Step 36 Create the OSC channels using the “NTP-G38 Provision OSC Terminations” procedure on page 3-84.
Stop. You have completed this procedure.
