5-22
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 5 Provision Transponder and Muxponder Cards
DLP-G319 Change the TXP_MR_10G or TXP_MR_10E Card Line Thresholds for 10G Ethernet LAN Phy
dot3StatsFCSErrors Number of frames with frame check errors, that is, there is an
integral number of octets, but an incorrect Frame Check Sequence
(FCS).
dot3StatsFrameTooLong Number of received frames that were larger than the maximum size
permitted.
etherStatsUndersizePkts Total number of packets received that were less than 64 octets long
(excluding framing bits, but including FCS octets) and were
otherwise well formed.
etherStatsFragments Total number of packets received that were less than 64 octets in
length (excluding framing bits but including FCS octets) and had
either a bad FCS with an integral number of octets (FCS Error) or a
bad FCS with a nonintegral number of octets (Alignment Error).
Note that it is entirely normal for etherStatsFragments to increment.
This is because it counts both runts (which are normal occurrences
due to collisions) and noise hits.
etherStatsPkts64Octets Total number of packets (including bad packets) received that were
64 octets in length (excluding framing bits but including FCS
octets).
etherStatsPkts65to127Octets Total number of packets (including bad packets) received that were
between 65 and 127 octets in length inclusive (excluding framing
bits but including FCS octets).
etherStatsPkts128to255Octets The total number of packets (including bad packets) received that
were between 128 and 255 octets in length inclusive (excluding
framing bits but including FCS octets).
etherStatsPkts256to511Octets Total number of packets (including bad packets) received that were
between 256 and 511 octets in length inclusive (excluding framing
bits but including FCS octets).
etherStatsPkts512to1023Octets Total number of packets (including bad packets) received that were
between 512 and 1023 octets in length inclusive (excluding framing
bits but including FCS octets).
etherStatsPkts1024to1518Octets Total number of packets (including bad packets) received that were
between 1024 and 1518 octets in length inclusive (excluding
framing bits but including FCS octets).
etherStatsBroadcastPkts Total number of good packets received that were directed to the
broadcast address. Note that this does not include multicast packets.
etherStatsMulticastPkts Total number of good packets received that were directed to a
multicast address. Note that this number does not include packets
directed to the broadcast address.
etherStatsOversizePkts Total number of packets received that were longer than 1518 octets
(excluding framing bits, but including FCS octets) and were
otherwise well formed.
etherStatsJabbers Total number of packets received that were longer than 1518 octets
(excluding framing bits, but including FCS octets), and had either a
bad FCS with an integral number of octets (FCS Error) or a bad FCS
with a nonintegral number of octets (Alignment Error).
Table 5-7 TXP_MR_10G and TXP_MR 10GE LAN Phy Variables (continued)
Variable Description
