Cisco ONS 15454 DWDM User Manual

Contents
v
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
NTP- G12 Install and Close the FMEC Cover (ETSI Only) 1-63
NTP- G13 Install the Rear Cover (ANSI Only) 1-64
NTP- G14 Install DWDM Equipment 1-66
DLP- G27 Install the DCU Shelf Assembly 1-67
DLP- G28 Install the Fiber Patch-Panel Tray 1-67
DLP- G29 Install the Fiber-Storage Tray 1-68
DLP- G30 Install the FlexLayer Shelf 1-68
DLP- G31 Install the FlexLayer Modules 1-69
DLP- G32 Install the Y-Cable Protection Modules 1-70
NTP- G15 Install the Common Control Cards 1-71
DLP- G33 Install the TCC2 or TCC2P Card 1-72
DLP- G34 Install the AIC-I Card 1-75
NTP- G16 Perform the Shelf Installation Acceptance Test 1-76
DLP- G35 Inspect the Shelf Installation and Connections 1-77
DLP- G36 Measure Voltage 1-78
CHAPTER 2 Connect the PC and Log into the GUI 2-1
Before You Begin 2-1
NTP- G17 Set Up Computer for CTC 2-2
DLP- G37 Run the CTC Installation Wizard for Windows 2-3
DLP- G38 Run the CTC Installation Wizard for UNIX 2-6
NTP- G18 Set Up CTC Computer for Local Craft Connection to the ONS 15454 2-9
DLP- G39 Set Up a Windows PC for Craft Connection to an ONS 15454 on the Same Subnet Using
Static IP Addresses
2-11
DLP- G40 Set Up a Windows PC for Craft Connection to an ONS 15454 Using Dynamic Host
Configuration Protocol
2-13
DLP- G41 Set Up a Windows PC for Craft Connection to an ONS 15454 Using Automatic Host
Detection
2-16
DLP- G42 Set Up a Solaris Workstation for a Craft Connection to an ONS 15454 2-19
NTP- G19 Set Up a CTC Computer for a Corporate LAN Connection to the ONS 15454 2-21
DLP- G43 Disable Proxy Service Using Internet Explorer (Windows) 2-22
DLP- G44 Disable Proxy Service Using Netscape (Windows and UNIX) 2-22
NTP- G20 Set Up a Remote Access Connection to the ONS 15454 2-23
NTP- G21 Log into the ONS 15454 GUI 2-24
DLP- G46 Log into CTC 2-25
DLP- G47 Install Public-Key Security Certificate 2-28
DLP- G48 Create Login Node Groups 2-28
DLP- G49 Add a Node to the Current Session or Login Group 2-30
DLP- G50 Delete a Node from the Current Session or Login Group 2-30

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
