NTP-G131 Convert DWDM Nodes to Hybrid Nodes
Note The Cisco MetroPlanner configuration file will label the OSC-CSM card as east even if it is
installed in the west side of the node.
a. To modify the OSC-CSM card line direction, double-click the OSC-CSM card in node view. The
card view appears.
b. Click the Provisioning > Optical Line > Parameter tabs.
c. In the Port 2 line, click the Line Direction drop-down list and choose East to West.
d. Click Apply.
Step 13 Calculate default connections using WDM-ANS:
a. Click the CTC up arrow to get back to node view.
a. In node view, click the Provisioning > WDM-ANS > Connections tabs.
b. Click the Calculate Connections button.
Step 14 Connect the cables from the OSC-CSM LINE ports to the OPT-BST amplifier OSC ports. Follow the
recommended connections that were automatically calculated in the Connections tab as described in
Step 13.
Step 15 Launch ANS port regulation:
a. In node view, click the Provisioning > WDM-ANS > Port Status tabs.
b. Click the Launch ANS button.
c. In the Link Status column, the ports change to Regulated.
Step 16 Create OSC terminations starting from the OSC-CSM card. See the “NTP-G38 Provision OSC
Terminations” task on page 3-84.
Step 17 (Optional) If you want to set up timing on the OSC-CSM card, create the timing source:
a. In node view, click the Provisioning > Timing tabs.
b. Scroll down to the Reference Lists area.
c. In the NE Reference column, select Internal Clock from the drop-down list for all entries where the
selected Clock Source is the OSC-CSM that you are adding.
d. Click Apply.
Step 18 (Optional) Complete the “NTP-G60 Create Overhead Circuits” procedure on page 7-13.
Step 19 Repeat Steps 3 through 18 for each OSCM card you are replacing in the node.
Step 20 If you are installing cross-connect cards, refer to the Cisco ONS 15454 Procedure Guide or the
Cisco ONS 15454 SDH Procedure Guide for instructions.
Stop. You have completed this procedure.
