Timing Reference
This chapter provides information about Cisco ONS 15454 users and node timing. To provision security
and timing, see the “NTP-G23 Create Users and Assign Security” procedure on page 3-5.
Note Unless otherwise specified, “ONS 15454” refers to both ANSI and ETSI shelf assemblies.
Chapter topics include:
• 21.1 Node Timing Parameters, page 21-1
• 21.2 Network Timing, page 21-2
• 21.3 Synchronization Status Messaging, page 21-3
21.1 Node Timing Parameters
SONET timing parameters must be set for each ONS 15454. Each ONS 15454 independently accepts its
timing reference from one of three sources:
• The building integrated timing supply (BITS) pins on the ONS 15454 backplane (ANSI) or
MIC-C/T/P coaxial connectors (ETSI).
• An OC-N/STM-N card installed in the ONS 15454. The card is connected to a node that receives
timing through a BITS source.
• The internal ST3 clock on the TCC2/TCC2P card.
You can set ONS 15454 timing to one of three modes: external, line, or mixed. If timing is coming from
the BITS pins, set ONS 15454 timing to external. If the timing comes from an OC-N/STM-N card, set
the timing to line. In typical ONS 15454 networks:
• One node is set to external. The external node derives its timing from a BITS source wired to the
BITS backplane pins. The BITS source, in turn, derives its timing from a primary reference source
(PRS) such as a Stratum 1 clock or global positioning satellite (GPS) signal.
• The other nodes are set to line. The line nodes derive timing from the externally timed node through
the OC-N trunk (span) cards. The DWDM node normally derives timing from the line using the
OSCM or OSC-CSM card that are inside an OC-3/STM-1 channel.
You can set three timing references for each ONS 15454. The first two references are typically two
BITS-level sources, or two line-level sources optically connected to a node with a BITS source. The third
reference is usually assigned to the internal clock provided on every ONS 15454 TCC2/TCC2P card.
