RUGGEDCOM ROX II

CLI User Guide

Chapter 7

IP Address Assignment

Example: Configuring the Device as a DHCP Server to

Support a Relay Agent 263

default-route 172.16.10.1

no broadcast

no domain

no dns-server

no static-route

no nis server

no nis domain

subnet-name "LAN B-10"

network-ip 10.10.10.0/24

shared-network LAN.10-LAN.172

options

no unknown-client

ippool LAN-B_VLAN3

no unknown-client

iprange 10.10.10.10

end 10.10.10.200

option82 LAN-B_Option

remote-id 00:0a:dc:00:00:00

circuit-id 00:03:00:02

client

no hostname

no subnetmask

default-route 10.10.10.1

no broadcast

no domain

no dns-server

no static-route

no nis server

no nis domain

subnet-name mainSub

network-ip 192.168.0.0/24

shared-network LAN.10-LAN.172

options

no unknown-client

client

no hostname

no subnetmask

no default-route

no broadcast

no domain

no dns-server

no static-route

no nis server

no nis domain
