Siemens RUGGEDCOM ROX II User Manual

Chapter 10
Serial Server
RUGGEDCOM ROX II
CLI User Guide
344
Example: Serial Interfaces Configured as a Source for
Multicast Streams
interface switch.0010
interface switch.0020
For more information, refer to Section10.7.2, “Adding a Remote Host Interface”
7. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Step 2: Configure ser-1-2
1. Create a raw socket connection for ser-1-2:
interface serial lm1 2 protocols rawsocket
For more information, refer to Section10.2.3, “Adding a Serial Port Protocol”.
2. Set the rawsocket of the local port to 10002:
setrawsocket local-port 10002
For more information, refer to Section10.2.6, “Configuring the Raw Socket Protocol”.
3. Set the transport method to UDP:
setrawsocket transport udp
For more information, refer to Section10.2.6, “Configuring the Raw Socket Protocol”.
4. Set the multicast group for the local host to 232.2.2.2 and the UDP destination port to 6001:
setrawsocket local-host 232.2.2.2 6001
For more information, refer to Section10.6.2, “Adding a Local Host”.
5. Set switch.0030 and switch.0040 as the interfaces for the remote host:
interface switch.0030
interface switch.0040
For more information, refer to Section10.7.2, “Adding a Remote Host Interface”
6. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
7. Verify the configuration by typing the following:
traceserial
Final Configuration Example
Serial Port 1 Configuration
serial lm1 1
no alias
protocols rawsocket
setrawsocket local-port 10001
setrawsocket transport udp
setrawsocket remote-host 232.1.1.1 5001
interface switch.0010
!
interface switch.0020
Serial Port 2 Configuration
serial lm1 2
no alias
