Chapter 12

Tunneling and VPNs

RUGGEDCOM ROX II

CLI User Guide

424 Example: Configuring an Encrypted VPN Tunnel

Parameter Value

Type address

Value 2.2.2.1

For more information about configuring connection ends, refer to Section12.8.9, “Configuring the

Connection Ends”.

g. Add subnet 192.168.50.0/24 for the left connection end. For more information, refer to

Section12.8.10.3, “Adding an Address for a Private Subnet”.

h. Configure the right connection end for the IPsec tunnel with the following public IP address parameters:

Parameter Value

Type address

Value 2.2.2.2

For more information about configuring connection ends, refer to Section12.8.9, “Configuring the

Connection Ends”.

i. Add subnet 192.168.60.0/24 for the right connection end. For more information, refer to

Section12.8.10.3, “Adding an Address for a Private Subnet”.

3. Configure Device B:

a. Configure a host name for the device. For more information, refer to Section5.2, “Configuring the Host

Name”.

b. Add a unique pre-shared key and configure the following parameters:

Parameter Value

Local Address 2.2.2.2/30

Remote Address 2.2.2.1/30

For more information, refer to Section12.8.5.2, “Adding a Pre-Shared Key”.

c. Add an IPsec connection and configure the following parameters:

Parameter Value

Startup Operation start

Authenticate By secret

Connection Type tunnel

For more information about IPsec connections, refer to Section12.8.6.2, “Adding a Connection”.

d. Configure an Internet Key Exchange (IKE) algorithm with default values. For more information, refer to

Section12.8.7.2, “Adding an IKE Algorithm”.

e. Configure an Encapsulated Security Payload (ESP) algorithm with default values. For more information,

refer to Section12.8.8.3, “Adding an ESP Algorithm”.

f. Configure the right connection end for the IPsec tunnel with the following public IP address parameters:

Parameter Value

Type address
