Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 13
Unicast and Multicast Routing
Example: Route Reflection in a VRF Instance 515
• Neighbor 1.1.2.1
Parameter Value
Neighbor IP Address 1.1.2.1
Autonomous System ID 100
• Neighbor 1.1.3.2
Parameter Value
Neighbor IP Address 1.1.3.2
Autonomous System ID 101
For more information, refer to Section13.8.6.2, “Adding a Neighbor”.
c. Define a redistribution metric for BGP of type connected. For more information, refer to
Section13.8.10.2, “Adding a Redistribution Metric”.
4. Configure R3
a. Enable BGP and configure the following parameters:
Parameter Value
Autonomous System ID 101
Router ID 5.5.5.3
For more information, refer to Section13.8.1, “Configuring BGP”.
b. Define the following BGP neighbor:
Parameter Value
Neighbor IP Address 1.1.3.1
Autonomous System ID 101
For more information, refer to Section13.8.6.2, “Adding a Neighbor”.
c. Define a redistribution metric for BGP of type connected. For more information, refer to
Section13.8.10.2, “Adding a Redistribution Metric”.
Verification
Verify the configuration by navigating to routing» status» bgp» route on R1. The following routes should be
displayed:
LOCAL AS
NETWORK ADDRESS SELECTED INTERNAL METRIC PREFERENCE WEIGHT PATH ORIGIN
-----------------------------------------------------------------------------------------
1.1.1.0/30
1.1.1.2 true true 0 100 0 Unspecified
1.1.2.0/30
1.1.1.2 true true 0 100 0 Unspecified
1.1.3.0/30
1.1.2.2 true true 0 100 0 Unspecified
