Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 13
Unicast and Multicast Routing
Viewing the Status of Dynamic BGP Routes 517
192.168.1.2 true true 0 100 0 IGP
192.168.6.0
2.0.0.1 true false 0 0 200 IGP
192.168.12.0
192.168.1.2 true true 0 100 0 IGP
192.168.13.0
0.0.0.0 true false 0 32768 IGP
The list provides the following information:
Parameter Description
network Synopsis:  A string
Network.
next-hop Synopsis:  A string
Next-hop address.
selected Synopsis:  { true, false }
Selected next-hop for this route.
internal Synopsis:  { true, false }
Internal route.
metric Synopsis:  A 32-bit signed integer
Metric value.
local-preference Synopsis:  A string
Local preference.
weight Synopsis:  A 32-bit signed integer
Weight.
as-path Synopsis:  A string
Path.
origin Synopsis:  A string
Origin.
To view the status of the dynamic BGP neighbor configured on the device, type:
show routing status bgp neighbor
If BGP neighbors have been configured, a table or list similar to the following example appears:
ruggedcom# show routing status bgp neighbor | tab
PREFIX
LOCAL AS
ID VERSION AS MSGRCVD MSGSENT UPTIME STATE RECEIVED NETWORK NEXT HOP
SELECTED INTERNAL METRIC PREFERENCE WEIGHT PATH ORIGIN
-------------------------------------------------------------------------------------------------------
13.13.13.2 4 2122 982 984 16:18:04 Established 2
13.13.13.0/30 13.13.13.1
true false 0 32768 IGP
192.168.12.0 13.13.13.1
true false 2 32768 Unspecified
The list provides the following information:
Parameter Description
id Synopsis:  A string
Neighbor address.
