Chapter 16
Traffic Control and Classification
RUGGEDCOM ROX II
CLI User Guide
706 Configuring QoS Marking
Parameter Description
op-chain { op-chain } Synopsis:  { forward, prerouting }
Default:  forward
A chain in which the operation will take place.
4. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Configuring a Continue Mark
1. Make sure the CLI is in Configuration mode.
2. Select the Continue option by typing:
qos traffic-control advanced-configuration tcrules name mark-choice continue
Where:
• name is the name of the traffic control rule
3. Configure the following parameter(s):
Parameter Description
continue-chain { continue-chain } Synopsis:  { forward, prerouting }
Default:  forward
A chain in which the operation will take place.
4. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Configuring a DSCP Mark
1. Make sure the CLI is in Configuration mode.
2. Select the DSCP Marking option by typing:
qos traffic-control advanced-configuration tcrules name mark-choice dscpmarking
Where:
• name is the name of the traffic control rule
3. Configure the following parameter(s):
Parameter Description
dscp-mark { dscp-mark } Synopsis:  { BE, AF11, AF12, AF13, AF21, AF22, AF23, AF31, AF32, AF33, AF41, AF42,
AF43, CS1, CS2, CS3, CS4, CS5, CS6, CS7, EF }
A DSCP class value chosen amongst the given list.
dscpchain { dscpchain } Synopsis:  { forward, postrouting, prerouting }
Default:  forward
A chain where the DSCP marking will take place.
4. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
