Operating Instructions Administrator Reference 2
196
2.
Menu Buttons
Buttons to configure the Network Interface Board
and confirm the status of the printer.
Note
❒ When you click [Network Config], a dialog
box appears requesting the user name and
password. Type only the password in this
dialog box. The factory default password is
"password".
❒ The password is the same as that used for
remote maintenance and that used in the
NIB Setup Tool. If you change a password
with the Web Browser, the other passwords
are also changed.
3.
Status
Displays the name and comments of the Network
Interface Board, and the printer status.
-
--
-Linking the address (URL) to the [Help] button
You can link the address (URL) of the [Help] button to the Help files on the computer or on a Web serv-
er.
A Copy the Help files on the CD-ROM to the desired location. The Help files are located in folders
labeled with abbreviated language names. For example, English Help files are in the [EN] folder. Be
sure to copy the entire [EN] folder to the new location.
B Using a Web Browser, navigate to the Top Page and click [Network config].
C Type your password, (it is not necessary to type a user name) and click [OK].
D Type the path to the Help files in the [Help URL] box.
If you copied the Help files to "C:\HELP\EN", type "file://C:/HELP/". For example if you copied
the files to a web server and the index URL is "http://a.b.c.d/HELP/EN/index.html", type "ht-
tp://a.b.c.d/HELP/".
E Click [Apply].
When a warning message appears, select to continue configuration.
