C From the [Print Server Information] menu, select [Print Server Configuration].
D From the [Print Server Configuration] menu, select [Printer Configuration].
E Select the printer which is indicated as "Not Installed".
Important
❒ Use the same number as that specified as Remote Printer No. using the NIB Setup Tool.
(Step
F
-D).
F If you change the name of the printer, type a new name.
A name "Printer x" is assigned to the printer. x stands for the number of the selected printer.
G As type, select [Remote Parallel, LPT1].
The IRQ, Buffer size, Starting form, and Queue service mode are automatically configured.
H Press the {
{{
{ESC}
}}
} key, and click [Yes] in the confirmation dialog box.
I Press the {
{{
{ESC}
}}
} key to return to [Print Server Configuration Menu].
K
KK
K
Assign print queues to the created printer as follows.
A From [Print Server Configuration Menu], select [Queues Serviced By Printer].
B Select the printer created in step
J
.
C Press the {
{{
{INSERT}
}}
} key to select a queue serviced by the printer.
Note
❒ You can select more than one queue at a time.
D Follow the instructions on the screen to make other necessary settings.
When you have finished the above steps, confirm that the queues are assigned.
L
LL
L
Press the {
{{
{ESC}
}}
} key until "Exit?" appears, and select [Yes] to exit PCONSOLE.
