Ricoh MP C2504 User Manual

Paper Feed Unit PB3150
Cause code Cause of jam
Late
Jam
Lag
Jam
Stay
Jam
Display
code
005 Paper not fed from tray 3 Y1
013 Vertical Transport Sensor (Tray 3) Y
053 Vertical Transport Sensor (Tray 3) Y
001 Vertical Transport Sensor (Tray 3) Y
Paper Feed Unit PB3220/PB3210
Cause code Cause of jam
Late
Jam
Lag
Jam
Stay
Jam
Display
code
005 Paper not fed from tray 3 Y1
013 Vertical Transport Sensor (Tray 3) Y
053 Vertical Transport Sensor (Tray 3) Y
001 Vertical Transport Sensor (Tray 3) Y
006 Paper not fed from tray 4 Y2
014 Vertical Transport Sensor (Tray 4) Y
054 Vertical Transport Sensor (Tray 4) Y
001 Vertical Transport Sensor (Tray 4) Y
Bridge Unit BU3070
Cause code Cause of jam
Late
Jam
Lag
Jam
Stay
Jam
Display
code
021 Paper Exit Sensor (Bridge Unit) D
022 Relay Transport Sensor (Bridge Unit) D
061 Paper Exit Sensor (Bridge Unit) D
062 Relay Transport Sensor (Bridge Unit) D
6. Troubleshooting
1002

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
