Ricoh MP C2504 - Paper Feed Mechanism

To Next Page

To Previous Page

No. Description No. Description

1 Upper limit sensor 2 Pick-up roller

Paper Feed Mechanism

No. Description No. Description

1 Pick-up arm 4 Paper feed roller

2 Upper limit sensor 5 Feed guide

3 Pick-up roller 6 Friction roller
