Ricoh MP C2504 - Power Supply Box

To Next Page

To Previous Page

• Do not touch the areas outlined in red in the following diagrams when replacing the PSU. Residual

charge on the board may cause electric shock.

100V 200V

1. Rear lower cover (page 412)

2. PSU (DC Power) [A]

Power Supply Box

1. Rear lower cover (page 412)

4. Replacement and Adjustment

620
