Ricoh MP C2504 - Pressure Roller Thermistor; Thermopile Unit

To Next Page

To Previous Page

4. Non-contact thermistor unit [A]

Pressure Roller Thermistor

1. Fusing entrance guide plate (page 542)

2. Fusing upper cover (page 544)

3. Fusing lower cover (page 545)

4. Pressure roller thermistor [A].

Thermopile Unit

1. Fusing unit (page 541)

4. Replacement and Adjustment

554
