Ricoh MP C2504 - Output Check Table

6-184-004 Shift HP Sensor ENG [0 or 1 / 0 / 1/step]
Gets the shift HP sensor information of non staple finisher.
(0: Sensor Off, 1: Sensor On)
6-184-005 Junction Solenoid HP Sensor ENG [0 or 1 / 0 / 1/step]
Gets the junction solenoid HP sensor information of non staple finisher.
(0: Sensor Off, 1: Sensor On, “0“ appears if sensor detects home position)
6-184-006 Exit Pressure Release HP Sensor ENG [0 or 1 / 0 / 1/step]
Gets the exit pressure release HP sensor information of non staple finisher.
(0: Sensor Off, 1: Sensor On)
6-184-007 Stapler HP Sensor ENG [0 or 1 / 0 / 1/step]
Gets the stapler HP sensor information of non staple finisher.
(0: Sensor On, “0“ appears if sensor detects home position)
6-184-008 Tray Full Detection Sensor 1 ENG [0 or 1 / 0 / 1/step]
Gets the tray full detection sensor 1 information of non staple finisher. (0: Paper
overflow )
6-184-009 Tray Full Detection Sensor 2 ENG [0 or 1 / 0 / 1/step]
Gets the tray full detection sensor 2 information of non staple finisher. (0: Paper
overflow )
6-184-010 Slide Door Open/Close Door
SW
ENG [0 or 1 / 0 / 1/step]
Gets the slide door switch information of non staple finisher.
(0: Close, 1: Open)
Output Check Table
Main Machine, Paper Feed Tray
5804 [OUTPUT Check]
Input and Output Check
475
