Gate/Pick-up Arm Drive Source
Output Drive source Default position Application
1st tray pick-up roller Paper feed motor
Pressure contact when
OFF
Loaded paper contact
and release change-
over
2nd tray pick-up
roller
Paper feed motor
Pressure contact when
OFF
Loaded paper contact
and release change-
over
Paper exit junction
gate
Paper exit solenoid
Paper exit path open
when OFF
Paper exit/ bridge unit
or 1-bin/duplex path
change-over
Bypass pick-up roller Bypass pick-up solenoid Clearance when OFF
Loaded paper contact
and release change-
over
Inter-Roller Transport Path
Distance units: mm
Md. From To Distance
1st tray paper
feed
Pick-up roller 1 Paper feed roller 1 30.0
Paper feed roller 1 Transport roller 1 43.0
2nd tray paper
feed
Pick-up roller 2 Paper feed roller 2 30.0
Paper feed roller 2 Transport roller 2 43.0
Transport roller 2 Transport roller 1 96.9
Registration
Transport roller 1 Registration roller 86.8
Registration roller
Paper transfer roller (image
transfer position)
95.5
Fusing
Paper transfer roller (nip) Fusing roller (nip) 85.0
Fusing roller (nip) Fusing exit roller 55.7
Paper exit Fusing roller (nip) Paper exit roller 143.6
7. Detailed Descriptions
1182
