Ricoh MP C2504 User Manual

Service Call 101-195
SC100 (Engine: Scanning)
SC No. Type Error Name/Error Condition/Major Cause/Solution
SC101-01 D LED Error (Scanning)
The white level peak did not reach the prescribed threshold when the
white guide plate was scanned.
• Scanner Carriage defective
• BCU defective
• Connector defective (disconnected, loose)
• Harness defective
• IPU defective
• Condensation in scanner unit
• White Reference Seal dirty or installed incorrectly (sheet-through
exposure glass)
• White Guide Plate, or White Roller dirty or installed incorrectly
(SPDF/ARDF)
6. Troubleshooting
770

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
