Transport Roller Drive Source
Output Drive source
Pick-up roller 1
Paper feed motor
Paper feed roller 1
Pick-up roller 2
Paper feed roller 2
Transport roller 1
Transport motor
Transport roller 2
Registration roller Registration motor
Paper exit roller Paper exit/ Pressure release motor
Reverse roller Reverse motor
Duplex entrance roller 1
Duplex entrance motor
Duplex entrance roller 2
Duplex transport roller
Bypass/Duplex motor
Duplex exit roller
Bypass feed transport roller
Bypass pick-up roller
Bypass paper feed roller
Bypass reverse roller
ITB drive roller (belt) ITB drive motor
Paper transfer roller ITB drive roller (Follows rotation of image transfer belt)
Fusing drive roller Fusing motor
Paper Feed/ Transport Section
1181

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
