Cause verification Problem Judgement

Press the 3rd switch from the right on the size switch of paper

feed tray 2 when seen from the front of the machine (Done

after detaching paper feed tray 2)

Parameter other than 00001101

Press the 4th switch from the right on the size switch of paper

feed tray 2 when seen from the front of the machine (Done

after detaching paper feed tray 2)

Parameter other than 00001110

Pull out paper feed tray 2 from the machine. Parameter other than 00001111

Solution:

• Reconnect the connector.

• Replace the sensor.

• Replace the Paper Transport IOB.

• Replace the harness.

2nd Paper Feed Tray

Check the 2nd tray set sensor to see if there are any

defects.

Replace the switch for the pick-up arm.

Does not shift to right door open status

Target Part/SP No.:Right Door Open/Close Switch / SP5-803-026 (Right Door Open/Close

Sensor)

Cause verification Problem Judgement

Manually press the referenced switch (Done after opening

the right door)

1: Open

Open the right door 0: Close

Solution:

• Reconnect the connector.

• Replace the sensor.

• Replace the Paper Transport IOB.

• Replace the harness.

6. Troubleshooting

1038
