Installation Procedure

• When installing this option, turn OFF the main power and unplug the power cord from the wall

socket. If installing without turning OFF the main power, an electric shock or a malfunction may

occur.

• When attaching this 1-bin tray unit at the same time as Bridge Unit BU3070 or Side Tray Type M3,

attach this tray first. Otherwise, the 1-bin tray’s exit tray cannot be attached due to the Bridge Unit

BU3070 or Side Tray Type M3.

• To use together with the “Internal Finisher SR3130”, first attach the bottom plate of Internal Finisher

SR3130, and then install the 1-bin tray.

1. Remove the orange tape and shipping retainers.

2. Remove the accessories (fixing screws, etc.) provided with the machine.

3. Open the right door, and then remove the small cover [A].

4. Remove the screw and connector, and then remove the front upper cover [A].

2. Installation

166
