Ricoh MP C2504 - Special Tools

To Next Page

To Previous Page

Special Tools

Item Part Number Description Q’ty Unique or Common

1 A1849501

Scanner Positioning Pin

(2pcs/set)

1 C (General)

2 B6455020 SD Card (1GB) 1 C (General)

3 B6455060 SD Card (16GB) 1 C (General)

4 52039502 Silicone Grease G-501 1 C (General)

5 A2579300 Grease Barrierta – S552R 1 C (General)

6 C4019503 20× Magnification Scope 1 C (General)

7 VSSG9002

FLUOTRIBO MG GREASE:

100G

1 C (General)

8 A0929503

C4 Color Test Chart (3 pcs/

set)

1 C (General)

• A PC (Personal Computer) is required for creating the Encryption key file on an SD card when

replacing the controller board in which HDD encryption has been enabled.

Special Tools

401
