Initial Jam: Cause Code 001 / Location Code C
Target Part/SP No.: Fusing Entrance Sensor / SP5-803-006
Cause verification Problem Judgement
Execute an INPUT check when there is no paper at the position of
the referenced sensor.
0: Paper detected
Execute an INPUT check when there is paper at the position of the
referenced sensor.
1: Paper not detected
Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Target Part/SP No.: Fusing Exit Sensor / SP5-803-007
Cause verification Problem Judgement
Execute an INPUT check when there is no paper at the position of
the referenced sensor.
0: Paper detected
Execute an INPUT check when there is paper at the position of the
referenced sensor.
1: Paper not detected
Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Target Part/SP No.: Paper Exit Sensor / SP5-803-008
Cause verification Problem Judgement
Execute an INPUT check when there is no paper at the position of
the referenced sensor.
0: Paper detected
6. Troubleshooting
1010
