Ricoh MP C2504 User Manual

No. Description Cause Retry
16 - 19 Communication error
(interrupted)
Noise, Incorrect connection 3
21 - 24 Communication timeout Noise, Incorrect connection, Malfunction 3
26 - 29 Device stops (logically) Noise, Incorrect connection, Malfunction 3
31 - 34 Full of buffer (request) Noise, Incorrect connection, Malfunction 3
36 - 39 Verification error Noise, Incorrect connection 2
SC No. Type Error Name/Error Condition/Major Cause/Solution
SC687-00 D PER Not Received Error
Unable to receive the PER command from the controller.
Communication error
Replace the BCU.
SC600 (Controller)
SC No. Type Error Name/Error Condition/Major Cause/Solution
SC632-00 D Counter device error 1
After 3 attempts to send a data frame to the optional counter device via
the serial communication line, no ACK signal was received within 100
ms.
Serial line between the optional counter device, the relay board and
copier control board is disconnected or damaged.
• Turn the main power off/on.
• Check the serial communication line.
Service Call 620-687
877

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
