Ricoh MP C2504 - Image Transfer Belt

To Next Page

To Previous Page

Image Transfer Belt

• Do not touch the rollers but hold the upper/lower resin part [A] when you lift the Image Transfer

Unit. Touching the rollers may cause poor image quality.

1. Image transfer belt unit (page 474)

2. Bracket [A]

Image Transfer Unit

483
